Technical Illustrator/Technical Manual Designer

Executech Search and Selection
Full-time
On-site
Ekurhuleni (East Rand), South Africa
- All Characteristics
Reference: RS000194-CB-1

Are you a technical creative with a passion for heavy machinery? Join a leading mining equipment company where you’ll create clear, high-quality technical illustrations and manuals for underground and open-cast equipment, while building a solid future with industry giants.

Duties & Responsibilities

  • Diploma or Certificate in Technical Illustration, Mechanical Engineering, Drafting, or similar
  • 3–5 years’ experience in technical illustration and manual design within a manufacturing or heavy-equipment environment
  • Produce accurate 2D/3D technical illustrations (exploded views, assemblies, schematics) for underground mining machinery
  • Proven experience producing manuals for mechanical or industrial machinery
  • Proficient in SolidWorks Composer, SolidWorks / Inventor, AutoCAD, Adobe Illustrator & InDesign
  • Strong understanding of mechanical assemblies and engineering drawings
  • Excellent written and visual communication skills (English)
  • Design and compile operator manuals, maintenance & service manuals, parts catalogues, and technical training documentation
  • Interpret engineering drawings, CAD models, and BOMs to ensure technical accuracy
  • Ensure documentation complies with OEM standards, MHSA requirements, and internal quality systems
  • Liaise with Engineering, Production, Service, and Training teams to gather technical input
  • Maintain document control, version management, and updates aligned with engineering changes
As Specialist Recruiters for professionals in your industry, we are well geared to represent your best career interests. Whether you are an active job seeker or just browsing, let’s have a no stress conversation about your next career move!

It’s always good to have a great recruiter looking out for you!
For more exciting positions visit our website www.executech.co.za or Call us on 011 442 0644 and quote this advert.

Please note if you have not received feedback within two weeks, please consider your application unsuccessful for this particular opportunity.

Package & Remuneration

Market Related plus Benefits
